◎Upgraded wireless cloud transmission function;
◎Adopt three anti-shell design, waterproof, dust-proof and shock-proof;
◎Large screen high resolution LCD screen, the interface has Chinese prompts, more intuitive display content;
◎Built-in large capacity memory card, storage capacity upgrade;
◎USB transmission simulates the host computer as a U disk and reads data as easily as a U disk.
◎Real-time display of protective layer thickness and steel signal image, minimum automatic locking;
◎Dual-range operation mode can effectively ensure the detection accuracy and maximum detection depth;
◎Automatic storage of test data, on-site statistical analysis results are provided immediately, which is convenient for guiding construction work;
◎Professional data analysis software, so that your post-processing data and report generation work can be easily completed.
|
Product Model |
IWIN-RBL |
IWIN-RBL+ |
|
|
Applicable range of protective layer thickness (mm) |
Ф6mm～Ф50mm |
Ф6mm～Ф50mm |
|
|
First Range |
6mm-90mm |
6mm-90mm |
|
|
Second Range |
6mm-200mm |
6mm-200mm |
|
|
Maximum Allowable Error Of Second Range Protective Layer Thickness |
±1（mm） |
6~79mm |
6~79mm |
|
±2（mm） |
80~119mm |
80~119mm |
|
|
±4（mm） |
120~139mm |
120~139mm |
|
|
±6（mm） |
140~200mm |
140~200mm |
|
|
Applicable Scope of Diameter Estimation |
Ф6mm~Ф32mm |
Ф6mm~Ф32mm |
|
|
Maximum error of diameter indication |
±1Specifications |
±1Specifications |
|
|
Section grid |
not support |
Graphics + Digital Display |
|
|
Storage Quantity |
2000 Components*1000 Measuring Points |
2000 Components*1000 Measuring Points |
|
|
Data transmission mode |
USB、Wireless Cloud Transport (Options) |
USB、Wireless Cloud Transport (Options) |
|
|
Power supply mode |
lithium battery |
lithium battery |
|
|
Host parameters |
Waterproof parameters：IP65 |
Waterproof parameters：IP65 |
|
|
Screen size: 5 inches |
Screen size: 5 inches |
||
|
Resolving power：320×240 |
Resolving power：320×240 |
||
|
volume：195×140×45mm |
volume：195×140×45mm |
||
|
weight：0.8kg |
weight：0.8kg |
||
|
Large capacity lithium battery for more than 12 hours |
Large capacity lithium battery for more than 12 hours |
||
|
Working environment requirements |
temperature：-10℃～+40℃ |
temperature：-10℃～+40℃ |
|
|
humidity：＜90%RH |
humidity：＜90%RH |
||
|
Other requirements |
There is no corrosive gas in the air. No strong electromagnetic interference There should be no major shocks or shocks. Instruments to avoid direct sunlight |
||
|
Packing specification |
Material: Engineering Plastics Volume: 420*140*335mm Weight: 5.5kg |
||
