CBFI BF15000 15 Tons Per Day Ice Flake Machine For Cooling Use
15 tons 24 hrs flake ice machine BF15000 is very suitable for fresh fish cooling. Our machine is very welcomed in aquatic product processing plant. Flake ice is soft and thin, and do no damage to the skin of the fish. Contact us for more details.
Main Features
● Daily Capacity: 15 ton 24 hrs
● Containerized system is available, it is movable. And the ice machine is pre-installed.
● Machine power supply: 3 phase industrial power supply
● PLC controlling system, very easy to use.
● Design available for water lacking areas to use sea water to produce ice.
● With a rake system you can achieve automatic producing.
● Low temperature: ice temperature -8 degree
● Flake Ice shape with excellent cooling performance
● No sharp edges, so it no hurt the cooling products
● 1~2 mm thickness, no need to crush and can use at any time
Flake ice Machine Application
Dye-chemistry industry,
large concrete project,
large crude and fresh supermarket,
meat process,
large fishery wholesale market,
food processing company and more
Product Parameter
| Flake Ice Machine Parameters | |||||||
| Model | Daily output (T/24h) |
Cooling Method |
Compressor Power |
Fan Power for Cooling Tower | Cooling Pump Power |
Unit size (L*W*H mm) | Unit N.W. (kg) |
| BF500 | 0.5 | Air | 4.1kw | — | — | 1280*800*800 | 160 |
| BF1000 | 1 | Air | 7.44kw | — | — | 1320*900*900 | 210 |
| BF2000 | 2 | Air | 10kw | — | — | 1750*1100*1050 | 360 |
| BF3000 | 3 | Water | 8.45kw | 0.37kw | 1.5kw | 1500*1250*1260 | 1000 |
| BF5000 | 5 | Water | 13.49kw | 0.75kw | 2.2kw | 1900*1500*1470 | 1100 |
| BF6000 | 6 | Water | 19.94kw | 0.75kw | 2.2kw | 1900*1500*1470 | 1100 |
| BF8000 | 8 | Water | 24.2kw | 1.5kw | 2.2kw | 2400*1900*1860 | 1300 |
| BF10000 | 10 | Water | 33.8kw | 1.5kw | 4kw | 2500*2000*1860 | 1500 |
| BF15000 | 15 | Water | 44.5kw | 1.5kw | 4kw | 3350*2150*1960 | 3200 |
| BF20000 | 20 | Water | 64kw | 1.5kw | 5.5kw | 3400*2220*2230 | 4200 |
| BF25000 | 25 | Water | 76.5kw | 2.2kw | 5.5kw | 3700*2250*2510 | 4600 |
| BF30000 | 30 | Water | 93.7kw | 2.2kw | 7.5kw | 4700*2250*2520 | 5000 |
| BF40000 | 40 | Water | 118kw | 2.2kw | 7.5kw | 5000*2300*2700 | 7500 |
| ♦ Compressor Brand: Bitzer / Hanbell; Refrigerant: R22/R404A or Ammonia R717; ♦ Power Supply: Voltage 380V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately). ♦ Operating Conditions: T(water supply) : 20 ° C, T(ambient) : 32 ° C, T(condensing) : 38 ° C,T(evaporating)：-20℃. ♦ (Note: The actual ice production varies due to the influence of water supply temperature and ambient temperature.) ♦ (The final interpretation of the above metioned parameters is in Icesource, there will be no further notice, if there is any technical change.) |
|||||||
Product Details
Ice Rake System
For large capacity ice plants we can provide you ice rake cold storage to install an automatic ice plant. This system allows you to decrease the labor cost, and enhance the working efficiency.
Automatic Control System
We use Siemens PLC and touch screen for the control system. The system is easy to use, and highly automatic.
Pressure Control System
We use Danfoss pressure protector and pressure gauge build a pressure control system. The good quality of the components ensure the stable pressure in the system.
